This X-ray apparatus features full wave rectification and modular X-ray tube head. The frame of the unit, of cantilever construction, is compact in design easy of movement. The machine can be used for radiography in hospital wards or operating rooms.
Specifications
1.Power requirements
Voltage:180-240V Frequency:50Hz
Internal resistance: ≤1ΩRating:5k VA
Current:Maimum15Afor radiography
2.Time:0.063 to 5.0 steps electronic
3.Maximum height from X-ray tube focus to floor>1720mm
4.Minimum height from X-ray tube focus to floor<500mm
5.Collimator:Maximum film size at1000mm
Focal distance: 400×400mm
6.Maximumermote control distance:6m
7.X-ray tube focus: 2.6
8.Unit moving force: ≤250N
9.Net weight of the unit:95kg
