Veterinary Infusion Pump AJ-IP66VET
ADVANTAGE
1. First one New design in the market: independent 3 stage peristaltic device which it making infusion set stress evenly and improving infusion accuracy and extending the life of infusion pump and IV set, reduce workload and the patient more comfortable in infusion.
2. 3.5”touch screen, easy to operation.
3. Doorless structure design, very convenient to place IV set.
4. Double CPU. IP34warterproof / dustproof/shockproof.
5. AC/DC/Large battery capacity 2600 mhA. long working time.
6. Very Light weight, only 1.3 KG. Compact and Delicate.
FEATURES
Special Researcch for Veterinary Application
Focus on Veterinary Market
Good feedback from global thousands of Veterinary Hospitals, Veterinary Clinics and Pet Shops
3.5”Touch Screen
Independent 3 stage peristaltic device which it making infusion set stress evenly and improving infusion accuracy and extending the life of infusion pump and IV set, reduce workload and the patient more comfortable in infusion.
SPECIFICATIONs
Double CPU. IP34warterproof / dustproof/shockproof.
Flow Rate range: 0.1~1200.00ml/h, increment 0.01ml/h.
VTBI: 0.0-9999.99ml, Time: 1s-99h59min.
KVO: 0.1~5.0ml/h, increment 0.1ml/h.
Accuracy: ±5% (use the IV set calibrated)
Purge: 0.1-1200ml/h. IV sets: Dia3-5mm or setting
Bolus rate: 0.1~1200ml/h, Automatic/Manual bolus available
Bubble size: Adjustable 50/100/250/500/800 μl. Ultrasonic detection.
Occlusion pressure detection: Adjustable Low /Medium /High.
History Record: 2000 above. Night mode: setting and adjustable.
Temperature:-22℃-55℃,Relative humidity:10%-95%,
Atmospheric pressure: 40~120Kpa.
Alarm: Air Bubble, occlusion, infusion finished, standby time end,
low VTBI, low & empty battery, AC/battery disengaged, motor / pump /pressure sensor/ parameter error, system abnormal.
Size: L165 × W103 × L100mm. Weight: 1.3kg.
Power: 100~240V, External DC Power: 10V~16V
Battery: 2600mAh, working 8 hours above in 25ml/h speed.
