Standard Accessories
Aluminum alloy base plate (stable, practical, attractive and durable) ----1set
24V noiseless DC motor chair ----1set
Auto spittoon flushing and cup filler control system ----1set
Purified water-supplied system ----1set
Inductive air-locked rotary arm system ----1set
Rotatable tempered glass spittoon ---1set
Multifunctional foot controller ---1set
Junction box ---1set
Luxurious dental sense operation light ---1set
LED X-ray film viewer ---1set
Seamless cushion(with foldable headrest) ---1set
Dental stool ---1set
Three way syringe (cold & hot) ---2pcs
American Hand piece tubine connector ---3sets
American tubes and pipes ---1set
Options
Three memory position system
Curing Light
Scaler
Oil-free Air compressor
Intra oral camera with monitor
Hand pieces kit
Sense dental operation light
Two-way or four-way high speed air turbine H.P
Two-way or four-way low speed air motor H.P
Genuine-leather chair cushion
Specifications
(Voltage can be based on customer demand changes)
Supply Pressure: 100V-240V 50/60Hz
Air Pressure: 0.55Mpa
Water Pressure: 0.2MPa-0.4Mpa
ITEMS |
Technical performances |
structural style |
full-automatic Integral dental unit |
supply voltage |
AC220V 50HZ |
Handpiece system configuration |
seton adopt down-hanging |
high-speed air turbine handpiece |
No-load speed air pressure: 0.22MPa time rotate speed≥35X104r/min, |
low-speed air turbine handpiece |
No-load speed air pressure:0.33MPa time rotate speed≥18X103r/min |
handarm |
Support air, water and fog |
mouth lamp |
Halogen illuminance:10000LX~15000LX |
film viewer |
Voltage: 24V power: 8 illuminance: ≥2000LX |
Gas displacement |
55L/min |
air supply pressure |
0.55Mpa.8Mpa |
Water supply pressure |
0.2Mpa~0.4Mpa |
instrument tray |
degree of skewness≦3° supporting free lifting in certain range,and stay at random |
Built-in water purification system |
prolong handpiece’s working life |
dental chair |
Load capacity of ANJUE series integral dental unit ≥1323N lifting and supination: DC motor motor:24V DC motor Range of lifting height (from ground)≤600mm,≥800mm Hypsokinesis range of backrest: 1050~1070mm Maximal hypsokinesis of cushion≥100 Up-down move of head support:100mm |
Chair of doctor |
Range of lifting height(from ground):420-560mm adjustable |
