Vertical Laminar Flow Clean Benches Specifications
Model |
BSC-680II |
BBS-DDC |
BBS-1300VGS |
BBS- SDC |
BBS-SDC2100 |
|
External size (W x D x H) |
680x400x1158 |
1040×600×1730 |
1310*750*2000 |
1440*600*1730 |
2100*740*2550 |
|
Internal size (W x D x H) |
630x375x615 |
940*580*540 |
1200*645*610 |
1340*580*540 |
2000*705*1100 |
|
Display |
LED Digital display |
|||||
Pre-Filter |
Disposable, non-washable polyester fibre |
|||||
HEPA Filter |
Efficiency >99.995% at 0.3μm |
|||||
Airflow Velocity |
Laminar Airflow Velocity Average of 0.3~0.5m/s |
|||||
Noise Level |
<60 dBA |
|||||
Fluorescent Lamp |
14W*1 |
21W*1 |
28W*1 |
28W*1 |
36W*1 |
|
UV Lamp |
15W*1 |
20W*1 |
30W*1 |
30W*1 |
30W*1 |
|
Power Consumption |
160W |
340W |
600W |
480W |
1200W |
|
Front Sash |
Tempered glass, no less than 5mm,anti-ultraviolet radiation. |
|||||
Main Body Material |
Adopting cold-roll steel plate with corrosion-proof coating |
|||||
Working Zone Material |
304 stainless steel |
|||||
Base Stand Material |
Adopting cold-roll steel plate with corrosion-proof coating |
|||||
Base Stand Height |
650mm, Caster : Reverse Wheel with brake |
|||||
Electrical |
110~240V/50HZ/60HZ |
|||||
Certification |
ISO-9001,ISO-14001,ISO-13485,CE |
|||||
Standard Accessory |
Light, UV, Water and gas Tap, |
Light, UV |
Light, UV, Water and gas Tap, base stand |
Light, UV |
Light, UV
|
|
Net Weight |
60kg |
110kg |
225kg |
160kg |
260kg |
|
Shipping Weight |
80kg |
150kg |
255kg |
210kg |
300kg |
|
Package size(W x D x H) |
900x610x1360 |
1200*750*1920 |
1500*1040*1700 |
1580*745*1950 |
2250*1000*2200 |
